This Pressure Transducer is Part of All New Product Line Up from The Pressure Transducer is made from High-Quality stainless steel material providing it with rigidity. The transducer comes with a standard thread size of G1/4 and can work in both air and water. The sensor gives a digital output in the range of 0.5V to 4.5V while operating at 5VDC. The sensor has stable performance characteristics with a long operation life.
Specifications
| Sensor Type | Analog Pressure Sensor |
| Material | Stainless Steel |
| Thread Size | G 1/4″ |
| Pressure Range (MPa) | 0 â 0.5 |
| Operating Voltage (VDC) | 5 |
| Output Voltage (VDC) | 0.5 ~ 4.5 |
| Accuracy | 1% FS |
| Length (mm) | 50 |
| Width (mm) | 20 |
| Height (mm) | 20 |
| Weight (gm) | 70 |
| Shipment Weight | 0.075 kg |
Features:
- Adopt Precision Compensation Technology and Sensitive Components, Stable and Reliable.
- 0.1% FS Small Output Error, Including Nonlinear, Hysteresis Error, and Repeatability.
- Light Weight and Small Volume, Easy to Install, and Operate.
- Stainless Steel Body, it has Complete Surge Voltage Protection Function.
Package Includes:
- 1 x 0.5MPa Stainless Steel Pressure Transducer Sensor
