It is an Ingenex 3-24VDC 50V solid state relay 2A, output with resistance type fuse 50V 2A. The input control signal voltage for the relay module is: (the state of the 0-2.5V low-level relay OFF; the state of the 3-24V high-level relay ON).
It refers to a high-level trigger signal between the trigger terminal (IN) and the negative power supply forward voltage is usually triggered by the positive electrode and the power supply connected to a terminalTypes of trigger mode, when the trigger end of the positive electrode voltage reaches the voltage or triggered, the relay is energized.
Specification:
- Operating Voltage (VDC): 3 ~ 24
- Supply Current (A): 2mA
- Switching Voltage (VAC): 50@2A
- Operating Temperature (°C): -40 to 85
- Opt. Relative Humidity(RH): 20% ～ 85%
- Storage condition (℃): – 65 to 125
- Length (mm): 34
- Width (mm): 26
- Height (mm): 22
- Weight (gm): 10
Package Includes:
- 1 x 1 Channel 3-24V Relay Module Solid State High-Level SSR DC Control DC with Resistive Fuse
