This is a high voltage step-up power supply module, which is commonly used in electronics experiments and demonstrations. The module can generate a voltage of up-to 1000KV from an input of 3-6V from a normal Li-ion battery. The high-voltage module uses the principle of the Tesla coil.
Specifications
Input Voltage (V) | 3.3V~5V DC |
Maximum Operating Current (A) | 2 – 5 |
Max. Output Voltage | 1000 KV |
Max. Output Current (A) | 0.5 A |
Discharge Time | 10s |
Color | Black |
Length (mm) | 8.8 |
Width (mm) | 2.67 |
Height (mm) | 2.3 |
Weight (gm) | 45 |
Shipment Weight | 0.05 kg |
Features:
- High-Quality Silicone Wires at Input and Output
- Creates an Arc of 1000KV
- Small in Size
- Easy to Use
Package Includes:
- 1 x 1000KV Step Up Power Module
