The resistance of 20mm GL20528 Light Sensitive Photoresistor LDR changes with the change in the ambient light exposed on the surface of the sensor. As the light on the sensor increases then the resistance across the two leads decreases. Light Dependent Resistor is a type of photocell which finds excellent use in light sensing device application, whether it is automatic outdoor light ON/OFF switch or indoor automatic light switch; moreover, the 12mm LDR or photoresistor sensor works best in both light and dark regions. The photo-resistor is a staple of electronics. If you need a way to sense the level of ambient light, then there is no easier way to do it without an LDR/photo-resistor.
Two Cadmium Sulphide PhotoConductive Cells with spectral responses similar to that of the human eye. Cell resistance falls with increasing light intensity. Applications of this product include smoke detection, automatic lighting control, batch counting, and burglar alarm systems. Furthermore, some of the applications are given below.
Specifications
| Diameter (mm) | 20 |
| Spectral Peak | 560 nm |
| No. of Pins | 2 |
| Dark resistance | max. 2 kΩ |
| Light Resistance | 10 – 20 kΩ |
| Maximum Voltage(V) | 500 VDC |
| Maximum Power (W) | 0.5 |
| Response Time ( μS) | 30 |
| Shipment Weight | 0.006 kg |
Features:
- Coated with epoxy
Good reliability
High sensitivity
Small volume
Fast response
Good spectrum characteristic
Model: GL20528 ( GM20528 )
Size: 20mm
Max. voltage: 500 VDC
Max. power: 500 mW
Spectrum Peak Value (nm): 560
Light resistance ( KΩ) : 10–20 kΩ
Dark resistance ( KΩ): 2 kΩ.
Υ value : 0.6.
Increase response time: 30 mS.
Decrease response time: 30 mS.
Package Includes :
- 1 x 20mm GL20528 Light Sensitive Photoresistor LDR.
