Arducam 5MP OV5647 Pan Tilt Camera for Raspberry Pi is an all-new pan and tilt mechanism for the 5MP OV5647 camera, which is compatible with the raspberry pi. This mechanism can move your camera in two dimensions with 180 degrees horizontal and 145 degrees vertical movements. The PTZ camera controller board outputs the PWM signals to drive the servo motors directly. Therefore, this can be used to monitor places that should be covered by multiple ones commonly in the surveillance system.
Features:
Camera
- Sensor: OV5647
- Resolution: 5MP 2592H x 1944V
- Frame Rate: 30fps@1080P, 60fps@720P
- IR Sensitivity: Integral IR filter, visible light only
- Field of View: 54°(H) x 41°(V)
- Camera Board Dimension: 25mm x 24mm
Digital Servo
- Torque: 0.6 kg/cm at 3.6V, 0.8 kg/cm at 4.8V
- Operating Speed: 0.13sec/60° at 3.6V, 0.09sec/60° at 4.8V
- Operating Voltage: 3.6v~4.8v
- Operating Current: <350mA
- Dead Band: 3 usec
- Dimension: 20mm x 8.75mm x 22mm
Control Board
- PWM Driver: PCA9685
- PWM resolution: 12-bit
- Ambient light sensor: TSL2581FN
- Ambient light resolution: 16-bit
- Communication interface: I2C
- Operating voltage: 3.3V/5V
- Dimension: 25mm x 61mm
