The 64-Bit WS2812B Round LED Board is a powerful, high-density lighting solution that integrates 64 individually addressable 5050 RGB LEDs into a sleek circular layout. Based on the widely compatible NeoPixel protocol, this module allows for the creation of stunning visual effects, including color sweeps, rotations, and complex animations, using only a single digital I/O pin. Each pixel is equipped with its own intelligent driver chip that handles signal reshaping and 24-bit color depth (8 bits per channel), resulting in over 16 million vibrant colors with 256 levels of brightness. The board is cascadable via DI/DO ports, enabling the connection of multiple rings for massive, synchronized displays. With its compact round form factor and standard 5V operation, it is a favorite for smart home ambient lighting, wearable technology, and high-impact DIY robotics projects.
Specification
| Communication Speed | 800 Kbps |
| Control Interface | Single-Wire Serial (DI/DO) |
| Input Voltage | DC 5V |
| LED Quantity | 64 Pixels |
| Max Power Consumption | 19.2W (All LEDs at full white) |
Features:
- 64 Individually Addressable Pixels: Complete control over every single LED in the circular array.
- Full Color Spectrum: 24-bit color depth achieves 16.7 million colors with high consistency.
- Single-Wire Digital Interface: Maximizes I/O efficiency on microcontrollers like Arduino, STM32, and ESP8266.
- Integrated Signal Reshaping: Built-in circuits prevent waveform distortion throughout the daisy chain.
- Robust 5050 SMD LEDs: High-brightness chips with a wide 120-140 degree viewing angle.
- Cascadable Design: Easily connect multiple modules for larger, more complex lighting configurations.
Package Includes:
- 1 x 64-Bit WS2812B 5050 RGB LED Round Development Board – Full Color Addressable
