Board Mount Humidity Sensors The BME280 is an integrated environmental sensor developed specifically for mobile
Specifications
| Operating Voltage (VDC) | 1.8 ~ 5 |
| Interface | I2C (up to 3.4MHz) |
| SPI (up to 10 MHz) | |
| Operating Temperature Range (°C) | -40 to 85 |
| Operating Humidity Range | 0-100% |
| Operating Pressure Range | 300-1100 hPa |
| Resolution | Temperature: +-1°C |
| Humidity: +-3% | |
| Pressure: +-1Pa | |
| I2C Address | SDO LOW: 0x76 |
| SDO HIGH: 0x77 | |
| Length (mm) | 12 |
| Width (mm) | 10 |
| Height (mm) | 2 |
| Weight (gm) | 3 |
| Shipment Weight | 0.005 kg |
Features:
- The BME280 is a great new chip that was originally designed for the next generation of smartphones.
- With an I2C connection, you have access to enough weather data to make some pretty good predictions for your local area.
- BME280, the precision sensor, is soldered onto PCB.
- Not only the pressure and the temperature, but this sensor can also measure humidity.
- It uses both I2C and SPI (supports 3-, 4-wire SPI) interface
Package Includes:
- 1 x GY-BME280-5V Temperature and Humidity Sensor
