HC-05 6 Pin Wireless Serial Bluetooth Module is a Bluetooth module for use with any microcontroller. It uses the UART protocol to make it easy to send and receive data wirelessly.
The HC-05 Wireless Bluetooth Module without Baseplate is a slave only device. This means that it can connect to most phones and computers with Bluetooth but it cannot connect to another slave-only device such as keyboards and other HC-06 modules. To connect with other slave devices a master module would be necessary such as the HC-05 version which can do both master and slave.
Specifications
| Input Supply voltage (V) | 3.6 ~ 6 |
| Input current (mA) | 50 |
| Maximum Operating Range (m) | 10 |
| Operating Frequency | 2.4GHz ISM band |
| Modulation | GFSK (Gaussian Frequency Shift Keying) |
| Emission power | 4dBm, Class 2 |
| Sensitivity | -84dBm at 0.1% BER |
| Operating Temperature (℃) | -20 ~ +75 |
| Length (mm) | 26.85 |
| Width (mm) | 13.13 |
| Height (mm) | 1.9 |
| Weight (gm) | 2 |
| Shipment Weight | 0.005 kg |
Features:
- Working current: matching for 30 mA, matching the communication for 8 mA.
- Dormancy current: no dormancy.
- Used for a GPS navigation system, water, and electricity gas meter reading system.
- With the computer and Bluetooth adapter, PDA, seamless connection equipment.
- Bluetooth module HC-08 Master and slave Two in one module.
- Use the CSR mainstream Bluetooth chip, Bluetooth V2.0 protocol standards.
- Potter default rate of 9600, the user can be set up.
- Bluetooth protocol: Bluetooth Specification v2.0+EDR
- Speed: Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous: 1Mbps/1Mbps.
- Security: Authentication and encryption.
- Profiles: Bluetooth serial port.
Package Includes:
- 1 x HC-05 Wireless Bluetooth Module without Baseplate
