The HW-290/GY-87 10DOF MPU6050+HMC5883L+BMP180 3-axis Gyro + 3-axis Acceleration + 3-axis Magnetic Field + Air Pressure Sensor has 3 in one MPU6050 3x Axis accelerometer sensor and 3x Axis gyroscope sensor, HMC5883L Triple Axis Magnetometer, BMP180 Barometric Pressure Sensor.
Specifications
| Type | GY-87 |
| Driver IC | MPU6050+HMC5883L+BMP180 |
| Operating Voltage (VDC) | 3 ~ 5 |
| Gyro range(°/s) | ± 250, 500, 1000, 2000 |
| Acceleration range(g) | ± 2 ± 4 ± 8 ± 16 |
| Communication | I2C Protocol |
| Length (mm) | 22 |
| Width (mm) | 17 |
| Weight (gm) | 5 |
| Shipment Weight | 0.01 kg |
Features :
- 3-axis Gyro+Acceleration+Magnetic Fiel
- Air Pressure Module
- Build-in ultra-low noise linear LDO voltage regulator
- Built-in onboard filters, which reduce noise from motor and other high current electronics
- You can easily select two I2C addresses for MPU6050 by soldered jumper
- Power LED
- Build in the Logic level converter for I2C
- Designed for 5V logic level
Package Includes :
- 1 x 10DOF HW-290/GY-87 Sensor Module.
- 1 x Straight pin Male header
- 1 x Curved pin Male header.
