This is a LoRa 433MHZ SX1278 SX1276 Wireless Transmitter and Receiver RF Module. E32-433T30D UART is a 1W wireless transceiver module with LoRa spread-spectrum technology and has a long-range of 8000m, operates at 410~441MHz (Default: 433MHz), based on originally imported RFIC SX1278 & SX1276 from SEMTECH, transparent transmission is available, TTL level.
Specifications
| Model | E32-433T30D |
| Type | CDMA |
| Working Frequency | 433 MHz |
| RF connector | SMA-K |
| Input Supply Voltage (VDC) | 2.3-5.5V |
| Transmitting power | 10~20 dBm |
| Interface | UART |
| Receiving sensitivity | -146 dBm |
| Air data rate | 0.3k~19.2kbps |
| Buffer | 512 bytes buffer |
| Distance | 8000m |
| RF IC | SX1278 SX1276 |
| Shipment Weight | 0.03 kg |
Package Includes:
1 x LoRa 433MHZ SX1278 SX1276 Wireless Transmitter and Receiver RF Module 8000M E32-433T30D
