ACCEL is a motion sensor Unit. Integrated with ADXL 345, ACC is able to obtain 3- axis of Acceleration. ADXL 345 is a small, thin, ultralow power, 3-axis accelerometer with high resolution (13-bit) measurement at up to ±16 g. Digital output data is formatted as a 16-bit two’s complement and is accessible through the I2C digital interface. In this Unit, we used the I2C series interface.
Specifications
Interface | I2C |
Measurement Range | ± 16g |
Resolution | The resolution of 10-bit fixed resolution increases with the increase of g range, up to 13 bits at ± 16 g |
Cable Length (cm) | 20 |
Operating Voltage (VDC) | 500% |
Operating Current | 23uA |
Operating Temperature (°C) | -40 to 85 |
Length (mm) | 32 |
Width (mm) | 24 |
Height (mm) | 8 |
Weight (gm) | 4 |
Shipment Weight | 0.005 kg |
Features:
- Ultralow power
- Single tap/double-tap detection
- Activity/inactivity monitoring
- Free-fall detection
- I2C digital interfaces
- Wide temperature range
Package Includes:
- 1x 3-Axis Digital Accelerometer Unit
- 1x GROVE Cable
