MACH3 Interface Board CNC 5 Axis with Optocoupler latest upgrade 5 axis breakout board is specially designed for the CNC single axis 2-phase stepper driver controller, such as TB6560, M542, M542H, MA860H, 2M542, 2M982, DM542(A), DM860(A) etc. single axis stepper driver controller series. With this 5 axis
Specifications
| Input Power | Through PC USB port or 12-24V power supply |
| Compatible Stepper Motor Driver | Max 5, 2-phase Microstep controllers |
| Driver type | Pulse and Direction signal control |
| Weight (gm) | 78 |
| Dimensions (mm) LxWxH | 90 x 70 x 20 |
| Cable Length | 1.4 meter |
| Shipment Weight | 0.09 kg |
Features :
- Maximum support 5-axis stepper motor driver controllers
- Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
- USB power supply and peripherals power phase are separate to protect computer security.
- All the signals are to-isolate which can protect your computer security.
- 5-input interface to define the Limit, Emergence-Stop, Cutter alignment, etc.
- Wide input voltage range: 12-24V, and with anti-reverse function.
- One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
- Output 0-10V analog voltage for the inverter to control the spindle speed.
- All the way to the relay output port, control spindle switch. Output port P17 mouth.
- Open all 17 ports, which can be accessed with the optocoupler drive, 5-axis stepper motor can be controlled.
- Pin P1 as PWM outputs can be controlled with optocoupler input spindle governor.
- Can be accessed by a common cathode or common anode input level to 5V drive.
- All the way through the optocoupler isolated 0-10V analog voltage output can be controlled with the corresponding analog interface converter to control the spindle speed. Output port P1 port.
Package Includes:
- 1 x MACH3 Interface Board.
- 1 x USB to USB Cable(1.4 mtr)
