AFS01 is a highly accurate and fully calibrated micro-flow sensor for measuring non-corrosive gases, such as oxygen and nitrogen, which ensures high reliability and excellent long-term stability. The sensor includes a flow detection element and a high-performance CMOS microprocessor with 24bitAD acquisition. The product has the excellent quality, super-fast response, strong anti-interference ability, High quality and low price and so on. High integration, very suitable for high quality, mass production requirements, is a good choice for users, easy to partner with manufacturers of OEM applications.
Specifications
| Product Type | Micro flow sensor |
| Model No. | Model AFS01 |
| Supply voltage | 5V |
| Range specification | 20 , 30 , 50 , 100 , 200 , 500 , 1000 , 1200 , 2000 sccm |
| Test gases | Air,N2, O2, non – corrosive gases |
| Repeatability | ± 0.3 ~ ± 5 % FS |
| Accuracy | ± 3 ~ ± 5 % FS |
| The response time | 30 – 500ms |
| Zero drift | ± 0.2 ~ ± 0.5 % |
| The flow range | 0 – 200 sccm |
| Storing temperature | -25 ~ + 90 ℃ ; |
| Operating temperature | -25 ~ + 80 ℃ |
| Shipment Weight | 0.009 kg |
Features:
- 5V low working voltage
- After calibration, the product has the function of temperature compensation.
- Adopt MEMS to make process, high reliability
- I2C digital communication interface
- Ultra-low power consumption
- No zero drift
Package Includes:
- 1 x Microflow sensor Model AFS01
