This Multifunction Shield For Arduino Uno / Leonardo is all in one shield for beginner users of the Arduino Development Board.
This Arduino Uno and Leonardo compatible multifunction experimenter shield (HCARDU0085) has a large range of features which makes it ideal for beginners who just want to experiment and learn, or just as a general-purpose shield for more advanced uses.
Besides the feature-rich range of components fitted to the shield, there is also a range of expansion headers for convenient interfacing of external modules and components. The shield includes R3 type headers for easy connection to your Arduino board. If you have a pre R3 design Arduino, please check for compatibility before purchase.
Specifications
| Input Supply voltage (V) | 5-Jan |
| Length (mm) | 66 |
| Width (mm) | Feb-00 |
| Height (mm) | 21 |
| Weight (gm) | 2200.00% |
| Shipment Weight | 0.025 kg |
Features:
- 4 digit 7-segment LED display module driven by two serial 74HC595’s.
- 4 x surface mount LED’s in a parallel configuration.
- 10K adjustable precision potentiometer.
- 3 x Independent push buttons.
- Piezo buzzer.
- DS18B20 temperature sensor interface.
- LM35 temperature sensor interface.
- Infrared receiver interface.
- Serial interface header for convenient connection to serial modules such as Bluetooth, a wireless interface, voice module, a voice recognition module, etc.
Package Includes:
- 1 x Multifunction Shield For Arduino Uno / Leonardo.
