It is a 50Ω SMA (F) jack straight Panel Mount 2 Hole. This Straight flange mount SMA connector features a gold-plated brass body and mechanical interface. This female connector is suitable for applications including Wi-Fi equipment. It operates at a voltage rating of 500 V
and a frequency of 18 GHz.
Specifications
| Gender | Female |
| Impedance | 50 Ω |
| Operating Frequency | 18 GHz |
| Voltage Rating | 500 V |
| Body Orientation | Straight |
| Contact Plating | Gold |
| VSWR | 1.23 |
| Body Material | Brass |
| Operating Temperature | -65 to +165°C |
| Shipment Weight | 0.009 kg |
Features:
- Gold plated body
- Suitable for applications including Wi-Fi equipment
- Solder termination method
Package Includes:
- 1 x SMA (F) jack straight Panel Mount 2 Hole
