The TFMini micro LiDAR distance sensor for drones UAV UAS robots (12m) Laser Range Finder sensor has its unique optical, structural, and electronic designs, the product possesses 3 major advantages, low cost, tiny volume and low power consumption. It has built-in algorithm adapted to indoor and outdoor environments can guarantee an excellent ranging performance at a low cost and in a tiny volume, which highly expands the application fields and scenarios of LiDAR and lays a solid foundation for future “eyes” in the smart era.
Specifications
| Model | TFMini micro LiDAR |
| Operating Distance Range (Meter) | 0.3 ~ 12 |
| Average Power Consumption (W) | 0.12 |
| Operating Voltage (VDC) | 4.5 ~ 6 |
| Acceptance Angle | 2.3° |
| Accuracy | 1% (less than 6m), 2% (6m-12m). |
| Communication Interface | UART |
| Lense Viewing Angle (FOV) | 4° |
| Frequency Range | 100Hz. |
| Light Sensitivity | 70,000Lux. |
| Resolution Ratio | 5 mm |
| Wavelength (nm) | 850 |
| Dimensions in mm (LxWxH) | 42 x 15 x 16 |
| Weight (gm) | 7 |
| Shipment Weight | 0.01 kg |
Package Includes :
- 1 x TF Mini LiDAR Distance sensor.
- 1 x Extension cable.
