This is the PL2303 USB UART converter Board. This is a great little tool for embedded systems that require a serial connection to a computer. The board can simply attach to a USB-C bus and will appear as a standard COM port
Specification
| Operating Voltage(V): | 3.3 to 5 |
| No. of Pins | 4 |
| Supports OS | Win XP/7/8/10/11 and abobe |
| Shipment Weight | 0.015 kg |
Features:
- Adopts PL2303GS new version device
- Supports windows XP/7/8/10/11/…
- 3x VCCIO power mode via jumper setting:
- VCCIO – 5V: 5V output
- VCCIO – 3.3V: 3.3V output
- open the jumper: powered from target board (1.8V/2.5V/3.3V/5V)
- 3x LED indicators: TXD, RXD, PWR
Package Includes:
- 1 x PL2303 USB UART Board (type A) V2
- 1 x 4-pin custom connector jumper wire x1
