Winsen Air Quality Detection Module is an original and brand new ZP07 air-quality module that adopts a flat surface semiconductor gas sensor. The module has good sensitivity to volatile organic gases such as formaldehyde, benzene, carbon monoxide, ammonia, hydrogen, alcohol, and smoke of cigarette, essence &, etc. The module has been aging, debugged, adjusted, and calibrated. So it has a good consistency and high sensitivity.
Specifications
| Model Type | ZP07 |
| Physical Interface | XH2.54-4P terminal sockets |
| Detection Gas | Formaldehyde, Benzene, Carbon Monoxide, Hydrogen, Alcohol, Ammonia |
| Output Data | 0-3 grade pollution signal |
| Working Voltage | 5.0±0.2V DC (No voltage reverse connect protection) |
| Output | TTL level (200ohm protected resistance inside) |
| Operating Temperature | 0～50℃ |
| Operating Humidity | ≤95％RH |
| Working Current | ≤60mA |
| Length (mm) | 24 |
| Width (mm) | 20 |
| Height (mm) | 16 |
| Weight (gm) | 20 |
| Shipment Weight | 0.02 kg |
Features:
- High sensitivity to volatile organic gases
- Low power consumption
- 10 seconds to 3 minutes with auto-preheating function
- High cost-effective
Package Includes:
- 1 x Winsen Air Quality Detection Module
