YDLIDAR G2 is a 360 degrees 2D LiDAR (hereinafter referred to as G2) developed by the EAI team. Based on the principle of Triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 degrees to continuously output the angle information as well as the point cloud data of the scanning environment while ranging.
Specifications
| Product Type | LiDAR |
| Model | G2 |
| Brand | YDLIDAR |
| Maximum Supply Voltage (V) | 5.2 V |
| Operating Current (A) | 500mA |
| Field of View | 360° |
| Ranging Distance | 12m |
| Ranging Frequency | 5000 times per second |
| Angle Resolution | 0.864 (Frequency-12Hz) |
| Operating Temperature | 50 ℃ |
| Shipment Weight | 0.404 kg |
Features:
- 360 degrees scan ranging
- Stable performance and high accuracy
- Wide measuring range
- Strong resistance to ambient light interference
- Industrial-grade brushless motor drive, stable performance
- Laser power meets Class I laser safety standards
- 360 degrees omnidirectional scanning and 5-12Hz frequency
- Using optical and magnetic fusion technology to realize wireless communication and wireless power supply
- High-speed ranging, up to 5000Hz frequency
Packages Includes:
- 1 x YDLIDAR G2 360° 2D LiDAR
