YDLIDAR X4 is a 360-degree two-dimensional rangefinder developed by the YDLIDAR team. Based on the principle of triangulation, it is equipped with related optics, electricity, and algorithm design to achieve high-frequency and high-precision distance measurement. The mechanical structure rotates 360 degrees to continuously output the angle information as well as the point cloud data of the scanning environment while ranging.
Specifications
| Operating Voltage (VDC) | 5 |
| Range (m) | 0.12-10 |
| Scan Angle | 360° |
| Resolution | 0.48-0.52° |
| Scan Frequency (Hz) | 6 – 12 |
| Length (mm) | 101 |
| Width (mm) | 65.6 |
| Height (mm) | 51.8 |
| Shipment Weight | 0.2 kg |
Features:
- 360-degree omnidirectional scanning ranging distance measurement
- Small distance error, stable performance, and high accuracy
- 10m Ranging distance
- Strong resistance to ambient light interference
- Low power consumption, small size, and long life
- Laser power meets Class I laser safety standards
- Adjustable motor speed frequency differ from 6Hz~12Hz
- Ranging frequency up to 5K Hz
Package Includes:
- 1 x YDLIDAR X4 Range Finder
