Adafruit METRO is a derivative of the Arduino UNO board (RS 769-7409) so you can find plenty of projects and example code to use and adapt. Running the ATmega328P at 16 MHz with 32 KB of flash and 2 KB of RAM it is perfect for most simple projects. There are 19 GPIO pins including analogue inputs, hardware UART, SPI and I²C, timers and PWM. Logic level is 5 V but it can easily be converted it to 3.3 V.
Headers are assembled and soldered on for you and the board is fully tested.
Specification
| Processor | ATmega328 |
| RAM | 2 KB |
| Flash Memory | 32 KB |
| Communication Protocol | UART, SPI and I²C |
| Operating Power | Logic level is 5 V but it can easily be converted it to 3.3 V |
| Frequency (MHz) | 16 MHz |
| Shipment Weight | 0.028 kg |
Features:
- Easy reprogramming
- 2 KB of RAM
- 32 KB of flash
Package Includes:
- 1 x Adafruit METRO 328 Fully Assembled – Arduino IDE compatible – ATmega328
