GY-BME280-3.3 BME280 Atmospheric Pressure Sensor Module.ME-BME280 is a Breakout Board featuring a Bosch Sensortec ME280 Temperature, Humidity & Pressure Sensor.
ME-BME280 is a Breakout Board featuring a Bosch Sensortec ME280 Temperature, Humidity & Pressure Sensor.
The board has selectable I2C address jumper (solder link GS2), I2C pull-up resistors, 7 pin header 2.54mm, and two mounting holes 3.5mm.
Default setting of the board; single power rail Vdd=Vdd_IO (solder link GS1), pull-ups resistors (R2, R3) 10k, protocol selector resistor 0ohm (R1), decoupling capacitors 0.1uF on both power supply pins Vdd & Vdd_IO.
Specifications
| Model | GY-BME280-3.3 |
| Chip | BME280 |
| Power Supply | 3.3-5VDC |
| Peak Current | 1.12mA |
| Air Pressure Range | 300-1100hPa (equi. to +9000…-500m above sea level) |
| Temperature Range | -40 to +85 °C |
| Digital Interfaces | I2C (up to 3.4 MHz) |
| SPI (3 and 4 wire, up to 10 MHz) | |
| Length (mm) | 15.5 |
| Width (mm) | 12 |
| Height (mm) | 2.4 |
| Weight (gm) | 0.8 |
| Shipment Weight | 0.01 kg |
Features:
- Package 2.5 mm x 2.5 mm x 0.93 mm metal lid LGA
- Digital interface I2C (up to 3.4 MHz) and SPI (3 and 4 wire, up to 10 MHz)
- Supply voltage VDD main supply voltage range: 1.71 V to 3.6 V
- VDDIO interface voltage range: 1.2 V to 3.6 V
- Current consumption 1.8 uA @ 1 Hz humidity and temperature
- 2.8 uA @ 1 Hz pressure and temperature
- 3.6 uA @ 1 Hz humidity, pressure and temperature
- 0.1 uA in sleep mode
- Operating range -40…+85 C, 0…100 % rel. humidity, 300…1100 hPa- Humidity sensor and pressure sensor can be independently enabled/disabled
Package Includes:
- 1 x GY-BME280-3.3 Precision Altimeter Atmospheric Pressure Sensor Module
- 1 x 6 pin Male Header
